FEATURES
- Mirror Finish ID for easy and quick loading and unloading of membranes
- Multi-porting option available with 3.0” and 4.0” IPS grooved feed/ concentrate ports for connecting vessels to each other
- Quick lock head retention system for quick access to membranes
- Exteriors coated with high-gloss polyurethane paint for UV resistance
- Captured head seal prevents roll during head assembly fitting
- Compatible for using in brackish and high brackish applications for respective pressure ratings
- Available in code-compliant models only
- ASME and CE certified
SPECIFICATIONS
| CODELINE 80U30 | CODELINE 80U45 | CODELINE 80U60 | CODELINE 80U120 | |
|---|---|---|---|---|
| Drawing no. | 99021 | 99189 | 99186 | 99188 |
| Design/ Max. operating pressure | 300 PSI/20 Bar | 450 PSI/31 Bar | 600 PSI/41 Bar | 1200 PSI/83 Bar |
| Max. operating temperature | 190°F/ 88°C | 190°F/ 88°C | 190°F/ 88°C | 1500F/660C |
| Qualification pressure | 1800 PSI/124 Bar | 2700 PSI/186 Bar | 3600 PSI/248 Bar | 7200 PSI/497 Bar |
| Element length | 1-8 | 1-8 | 1-8 | 1-8 |
