FEATURES
- Side port options available with 1.5” diameter IPS grooved end
- Mirror finish ID for easy and quick loading and unloading of membranes
- Quick lock head retention system for quick access to membranes
- Exteriors coated with high-gloss polyurethane paint for UV resistance
- Captured head seal prevents roll during head assembly fitting
- Dual end connection of 1” FNPT or 1.5” IPS grooved connection in single head
- CE certified
SPECIFICATIONS
| ECOLINE 80-300 | ECOLINE 80-450 | |
|---|---|---|
| Drawing no. | 99196 | 99197 |
| Design/ Max. operating pressure | 300 PSI/20 Bar | 450 PSI/31 Bar |
| Max. operating temperature | 120°F/ 49°C | 120°F/ 49°C |
| Qualification pressure | 1200 PSI/82 Bar | 1800 PSI/124 Bar |
| Element length | 1-8 | 1-8 |
